9P Series Plastic Coated CdS Photocells from Selco Products Co.

The CdS Photocell Series can provide a cost-effective solution in many light switching applications. For example, an automatic lighting system for a parking lot usually requires a timer built into the circuitry. The need for an expensive timer and electric wiring to the light is eliminated by using a photoconductive CdS photocell. The sensor can be mounted right into the light circuitry, providing a low cost solution from moonlight to bright sun.

Features:

Plastic coated construction

Light sensing in the spectral range from 515 to 730 nm

Peak wavelength of 515 nm

Resisivity values ranging from 3K-ohms to 240-ohms max @ 10Lux at 2856K

Operating temperature range of -30 to+75°C

Sintered film fabrication for high sensitivity

Applied voltages at 25°C of 150 and 200 (Vdc)
