AlizÉ™ 1.7: NIR Imaging with this Versatile InGaAs Camera

The Alizé 1.7 from Photon etc. is a high-end, scientific-grade InGaAs camera with a pixel resolution of 640 x 512. The camera integrates performance with reliability and features high efficiency, low noise levelsand a quick frame rate that is compatible with an external trigger.

This can be achieved by a combination of the latest control electronics and a four-stage thermoelectric cooler (TEC) that can hold operating temperatures as low as −50 °C. In return, the TEC makes use of forced air cooling, which needs absolutely no maintenance compared to a water-cooled or liquid nitrogen-cooled unit.

The Alizé 1.7 is among the most affordable high-end InGaAs cameras that are commercially available.

Key Features

Measures around 0.45 to 1.7 µm

InGaAs FPA

Low noise level

Four-stage thermoelectric cooling

Most affordable high-end NIR-SWIR camera

Applications Overview

Pharmacology: In vivo NIR-II monitoring pharmacokinetics and biodistribution in real-time improves and replaces present methods utilized in the NIR-I and visible wavelengths.

Physiology: Users can study the physiological activity in vivo like the nervous system, the endocrine system, the gastrointestinal motility and digestive system, the heart blood circulation, the oxygen delivery to using matching, the water and salt balance, etc.

Clinical: Perfect for image-guided surgery as working in NIR-II than NIR-I offers higher tumor-detection sensitivity. It hasa higher tumor-to-normal-tissue signal ratio and also an improved tumor-detection rate.

Remote sensing: Aerial imagery offers foundational context and visualization of ground conditions. This empowers organizations to make crucial and time-sensitive decisions.

Process monitoring and inline sorting: Classifying systems for plastic versus biocomposite or paper versus cardboard help enhance the quality of the secondary material.

Mining and geology: It help geologists spend less time logging data and more on interpretation while enhancing quality, consistencyand timeliness of geological data captured.

Agribusiness: Enhance soil or food quality by examining the contaminants present in soils, the sugar or water content of fruitsor fat and protein levels in liquid.

Cooling Swir Sensors: An Overview

Dark current is considered to be a crucial parameter while trying to find ways to obtain a scientific imaging camera, particularly in the short-wave infrared (SWIR) region.

Great attention must be given to the cooling method utilized to improve this parameter. It comes with multiple cooling technologies, each having a few benefits and drawbacks. In its ZephIR and Alizé line of SWIR cameras, Photon etc. utilizes a four-stage thermoelectric (TE4) air-cooled system to improve the sensitivity of its imaging sensors.

Product Specifications

Source: Photon etc

Alizé 1.7x Alizé 1.7s
Focal plane array (FPA) InGaAs InGaAs
FPA size (px) 640 x 512 640 x 512
Pixel size (µm) 15 15
Spectral range (QE > 10%) 0.45 - 1.70µm at 25°C 0.95 - 1.70µm at 25°C and 0.91 - 1.64µm at -50°C
FPA operating temperature -50°C -50°C
Dark current (sensor at -50°C) Target at 21°C: <450 (Typ. ~ 300) ē/px/s Target at 21°C: <600 ē/px/s
Gain setting (ē/ADU) High: 2.67 | Low: 47.5 High: 2.2 | Med: 7.7 | Low: 93
Readout noise (ē) High: 22 | Low: 135 High: 35 | Med: 75 | Low: 350
Frame rate in CameraLink™ (fps) High: 105 | Low: 210 Up to 240 full frame. 1900 for a 64x64px ROI
Frame rate in USB 3.0 (fps) High: 110 | Low: 220 Up to 250 full frame. 1900 for a 128x128px ROI
Digitization (bits) 13 14
Quantum efficiency >70% 0.95 - 1.67µm at 25°C and>70% 0.89 - 1.62µm at -50°C >70% 1.00 - 1.65µm at 25°C and>70% 0.96 - 1.59µm at -50°C
Computer interface CameraLink™ or USB 3.0 CameraLink™ or USB 3.0
Dimensions 169 mm x 130 mm x 97.25 mm 169 mm x 130 mm x 97.25 mm
Weight 2.6 kg 2.6 kg
