ARL QUANT’X ED X-Ray Fluorescence Spectrometer

The ARL QUANT'X Energy-Dispersive X-Ray Fluorescence Spectrometer allows users to quickly and easily collect composition data from almost any type of sample. It measures a variety of materials, including bulk solids, granules, weak or crushed powders, fused beads, thin films, pastes, and liquids, for major, minor, and trace element counts.

With standardless software and accessories, this comprehensive benchtop EDXRF (Energy Dispersive X-Ray Fluorescence) system fulfills the elemental analysis requirements of main and contract laboratories, educational establishments, environmental sensing and chemicals, mining, forensics, food, cement, and metals industries.

Source: Thermo Fisher Scientific – Production Process & Analytics

For elemental analysis, the ARL QUANT'X EDXRF spectrometer offers the best possible combination of performance, adaptability, and dependability. Its close-coupled optics, tiny size, and advanced electrically cooled detectors allow for unparalleled analytical precision over a wide range of elemental concentrations, from ppm to %.

The ARL QUANT'X EDXRF is now even more powerful. The QUANT’X, which is equipped with the latest generation of high-efficiency SDD detectors, can handle high-count rates at excellent resolutions and delivers better performance from light to heavy elements.

Acorss the entire periodic table, the ARL QUANT'X increases accuracy and recognition limitations by a factor of two. The average counting time can also be optionally decreased by a factor of four, dramatically increasing sample throughput.

The SDD500G detector incorporates the latest advancements in detection technology, significantly enhancing the performance of the ARL QUANT’X spectrometer. It increases sensitivity for light elements such as fluorine and broadens the analytical range to include carbon.

Advanced Technology

Optional Thermo Scientific^™ UniQuant^™ software for superior standardless analysis

Optional: Latest generation SDD500G detector covering carbon to americium

High-quality SDD500 silicon drift detector covering fluorine to americium

High-performance, multi-element analysis

Cutting-edge Digital Pulse Processing (DPP) technology

Main Features

Advanced analytical algorithms for atypical materials

Allows sample analysis in air, vacuum, and helium

Compact footprint and ease of transport for field measurements

Complete laboratory start-up package included

Exceptional sensitivity for trace analysis

Expertise across hundreds of applications

Full technical applications support

High measurement throughput for process control

Large sample chamber, camera, and wide range of collimators

Mechanical simplicity and reliability

On-site, collaborative method development

Outstanding sample-handling flexibility

Proven hardware and all-inclusive software

Rapid, easy installation and complete on-site customization

Powerful, Easy to Use Thermo Scientific^™ WinTrace^™ Software

Fundamental Parameters (FP) and empirical approaches with standards

Limitless elements, unlimited number of standards

Multi-layer thickness and composition

Numerous excitation conditions with automated operation

Provision of nine languages. Capacity for more languages available

Simple results transmission to external computer or LIMS

Standardless and semi-standardless analysis

Optional UniQuant Advanced Standardless Analysis

A range of selectable reporting levels and formats clearly present the outcomes for any type of user.

All elements are always examined.

Each sample’s exclusive physical properties, i.e., area, height, and mass, are comprised in the calculation.

Long-term changes in X-ray tube output are rectified.

The optional UniQuant program collects all emission lines of all possible elements from fluorine to americium, heading beyond any other FP analysis (carbon to americium with SDD500G option). Thanks to the sample's comprehensive spectral profile, UniQuant can instantaneously rectify all possible overlap and background implications, which are particularly complex in energy-dispersive spectra.

UniQuant comes pre-calibrated and ready for use.

Recommended for Solving Analytical Problems In:

Aerosol particulate filters for air pollution monitoring

Catalysts and chemicals

Cement, kiln feed, and alternative fuels

Environmental uses

Forensics and trace element analysis

Gemstones, precious metals analysis

Metallurgical slags and mining ores

Nutritional supplements in food and feed

Observing corrosion of cooling water circuits

Oil industry products

Plastics and polymers

RoHS / WEEE screening for heavy metals in plastics

Soil contamination and other environmental screening

Thin films on filters, coatings on metals

Waste sludges and used oils
