BM-25 Diaphragm Switch: Point Level Detector for Bins and Chutes

The BM-25 diaphragm switch is a high or low-level alertpressure switch forbins containing non-hazardous, free-flowing dry materials.

Need an Inexpensive Level Switch? Want to Know When Bins are Full or Empty?

The BM-25 diaphragm switchescan help reduce overfilling and stop important grains and fertilizer from being wasted. With the help of the BM-25 diaphragm switch, users canrecognize whether chutes or conveyors are clogged without making a mess.

How it Works:

When material meets the level of the switch in the bin, a sensitive microswitch is activated, which is how a diaphragm (or pressure) switch works. It provides a high-, medium-or low-level warning that may be used to start or stop a procedure.

What to Use the BM-25 for:

Material density from 20 lb./cu. ft

Monitoring levels of dry, free flowing materials

Installation in ordinary locations

Detect plugging of chutes or conveyors

Eliminate overflow or maintain a certain level of material

Levels of grain, feed,or fertilizer

Point level detection in bins and silos

The BM-25 is ideal for agriculture cooperatives, farmers, or any business storing dry bulk solids.

Applications

Use this Pressure Switch in Many Materials

Wheat, barley, corn, soybeans, or milo

Crops that produce nuts like sesame, sunflower, or peanuts

Agricultural chemicals in granular form and dry fertilizer

Sawdust, pieces, or pellets of wood

Alumina, bentonite, or potash in powder form

Resin pellets or plastic and rubber beads, ground

Landscape supplies

Foodstuffs such as sugar beets, rice, wheat, or oats

Features

Features of this Reliable Point Level Switch

Internal or external mounting

Economical point level detection

Pressure sensing operation

Material for a silicone diaphragm

Robust design and simple construction

Nylon housing

Specifications

Specifications Users Need to Know About the BM-25

Output: Switch contact closure

Mounting: Internal or external

Diaphragm Material: Silicone

Operating Temperature: −40 °F to +185 °F (−40 °C to +85 °C)

Switch Ratings: 250 VAC, 15 A

Enclosure Material: Nylon

Wire Entry: ½” NPT
