CM-900: CO2 Industrial Fixed Gas Detector

TheCM-900: CO₂ Industrial Fixed Gas Detectoris designed to provide a gas safety solution for industries requiring measurement of up to 5% carbon dioxide levels to mitigate potential hazards. This device features an IP64 industrial enclosure, specially designed for harsh environments or areas requiring wash-down capabilities.

Features

4-20 mA output to communicate with (BMS) Building Management Systems

Fast and PreciseCO₂ measurements - monitors 0-5%

Users configurable 3-relays dependent upon application

Gain instant audible or visual alarms for potential leaks

Meets all NFPA, IFC, and NBIC CO2 Safety Code Requirements

1-year warranty

Models

O₂ Industrial Gas Detector(CM-902)

CO₂ Industrial Gas Detector (CM-900)

Specifications

Accuracy:+/-200ppm or +/-10% reading

Alarms:5,000 ppm TWA, 5,000 ppm, 3% CO₂ (configurable)

Alarm Relays:3

Alarm Response Time:< 60 seconds

CO₂ Measurement Range:0-5% (50,000 ppm)

Calibration:Manual with test gas or factory calibration

Dimensions:8.25 in x 6.25 in x 3 in

Display Resolution:10ppm at 0~10,000 ppm

Pressure Dependence:built-in barometer (50 to 110 kPa)

Response Time:CO₂: <2 minutes by 90%

Sound Alarm:80 db@10 cm

Operating Temperature:32 °Fto 122 °F(0 °C to50 °C)

Warm-Up Time:<60 seconds at 22 °C

Weight:1.5 lbs (monitor only)

Sensor Life Expectancy:>15 years

Electrical

Power Input:9~32 VDC (12~24 VDC recommended), 2 A.

Power Consumption:3 Watts

Ingress Protection:IP64

6 VDC battery backup connections

Relays:Peak Current < 2 A @ 30 VDC or 250 VAC, SPDT

Relay Color Coding:

Red & White = Normally Open

Blue & White = Normally Closed

Accessories

CM-900-CBL: CO₂ Industrial Gas Detector Cable

CM-900-CON: CO₂ Industrial Gas Detector Connector

CM-1029: Industrial Siren Strobe

CM-902: O₂ Industrial Gas Detector
