Containerized PEM Hydrogen Generators: 246 to 492 Nm³/h
In sites where plant space is at a premium, customers may choose to install their electrolyzers outside. In other cases, customers may prefer to configure an electrolyzer for a more turnkey operation. To fulfill those requirements, Nel Hydrogen recommends containerization.
The M Series MC250 and MC500 units are supplied and placed in free-standing containers for ultimate flexibility.
Containerized M Series electrolyzers can generate up to492 Nm3/hour of hydrogen gas at 99.9995% purity on-demand. Common applications include industrial process gas, renewable energy storage, and hydrogen fueling.
Features
Pure hydrogen at process pressure – up to 30 barg (435 psig) hydrogen and 99.9995% purity
Cost-effective hydrogen supply – tracks electric costs
Increased safety – caustic chemicals are not used
Virtually zero stored hydrogen – removes the hazard of flooding the space
Large capacity with minimal footprint – only a fraction of space needed compared to storing large volumes of gas or liquid hydrogen
Dependable supply of hydrogen—field-proven reliability
Containerized design – versatile plant configurations
Automated – safe operation without manual involvement
Specifications
Source: Nel Hydrogen
| Specifications | MC250 | MC500 |
|---|---|---|
| Net Production Rate | 246 Nm3/h (9,352 SCF/h) –531 kg/24 h | 492 Nm3/h (18,704 SCF/h) –1,062 kg/24 hh |
| Turndown Range | 10 to 100% | 10 to 100% |
| Power Consumption at Stack at 100% Capacity1 | 4.7kWh/Nm³ – 53.2 kWh/kg | 4.7kWh/Nm³ – 53.2 kWh/kg |
| Purity – with optional high purity dryer | 99.999+% | 99.999+% |
| O2-Content in H2 | <1 ppm v | <1 ppm v |
| H2O-Content in H2 | <5 ppm v | <5 ppm v |
| Delivery Pressure | 30 barg(435 psig) | 30 barg(435 psig) |
|
Dimensions Electrolyser Enclosure – W x D X H Power Supply Enclosure – W x D X H |
12.2 m x 2.5 m x 3 m(40 ft x 8 ft x 9.9 ft) 6.1 m x 2.5 m x 2.6 m(20 ft x 8 ft x 8.5 ft) |
12.2 m x 2.5 m x 3 m(40 ft x 8 ft x 9.9 ft) 6.1 m x 2.5 m x 2.6 m(20 ft x 8 ft x 8.5 ft) |
| Ambient Temperature (Low and High Ambient Temperature Options Available | -20 to 40ºC (-4 to 104ºF) | -20 to 40ºC (-4 to 104ºF) |
| Electrolyte | Proton ExchangeMembrane | Proton ExchangeMembrane |
| Feed Water Consumption | 0.9 l/Nm3 | 0.9 l/Nm3 |
For reference only—specifications are subject to change. Customers can contact Nel Hydrogen for solutions that best fit their requirements.
1 Beginning of life and dependent on configuration and operating condition.
2 Plus vent and rooftop equipment, site specific.
