Deltabar FMD71: A Electronic Differential Pressure System

The electronic dp Deltabar FMD71 from Endress+Hauser is a differential pressure system that is utilized to quantify the pressure or level, volume or mass of liquids in distillation columns/evaporators or pressurized tanks.

The high-pressure sensor (HP) quantifies the hydrostatic pressure. The low-pressure sensor (LP) assesses the head pressure. The level is estimated in the transmitter with the help of two digital values.The electronic dp system removes problems of conventional differential pressure measurements.

Image Credit: Endress+Hauser Ltd.

Image Credit: Endress+Hauser Ltd.

For differential pressure, volume, levelor mass measurement of liquids in distillation columns/evaporators and pressurized tanks.

Process connections: Threads, flangesand hygienic connections

Process temperature: −40 up to +150 °C (−40 to +302°F)

Measuring range: 100 mbar to +40 bar (6 to 600 psi)

Accuracy: Single sensor up to ±0.05%, system up to ±0.07%

International explosion safety certificates and hygienic approvals

Extended Selection

Highly functional and practical

High-end products

Image Credit: Endress+Hauser Ltd.

Benefits

Removes traditional mechanical problems leading to higher process availability and reliability

Availability of overload-resistant high-purity ceramic sensor (99.9% Al₂O₃)

With the new electronic differential pressure system architecture and design, safety risks are reduced

The lowest total cost of ownership as a result of decreased installation time, downtime, maintenanceand spare requirements

Long-term stability and high reproducibility

Constant health indication of the full system through HART-based diagnostic

Multivariable level measurement: HART-based differential pressure, head pressureand sensor temperatures from one system

Specs at a Glance

Accuracy

“PLATINUM” 0.05% of individual sensor

0.075% of individual sensor

Process Temperature

–25 to +150 °C (–13 to +302 °F)

Pressure Measuring Range

100 mbar to 40 bar (1.5 psi to 600 psi)

Process Pressure Absolute/Maximum Overpressure Limit

60 bar (900 psi)

Material Process Membrane

Ceramic

316L, AlloyC

Measuring Cell

100 mbar to 40 bar (1.5 psi to 600 psi)

Specifications

Source: Endress+Hauser Ltd.
