Detect Air and Gas Leaks with the SV600 Fixed Acoustic Imager

Users can envision the unheard and unseen with the power of acoustic imaging. The SV600 Fixed Acoustic Imager allows users to constantly detect, locateand visualize air and gas leaks or variations in sound signatures before they become costly issues.

Additionally, the SV600 can be fitted for a range of continuous acoustic imaging applications — such as a Boston Dynamics Spot^® payload.

Users can reduce operator intervention with a completely automated and combined solution

Track sound signature variations in real-time to avoid unplanned maintenance

Users can capture data from inaccessible or hazardous regions to keep the team safe

By utilizing a range of the latest sound sensors, the SV600 can be fitted near to any equipment or asset, to any area of the production line, or where human access is limited or risky to guarantee users can track the most significant parts of a facility without disruption.

The SV600 as a fixed, automated solution, combines with the user'sprocessand removes the need for prolonged fault-finding processes like soapy water tests when utilized as a part of their product leak testing process. By constantly tracking their surroundings, users can rapidly detect and fix air leaks. This helps decrease the consumption of compressed air and energy to help save the user's facility money.

Key Features

High-end 24/7 acoustic monitoring

Microphones with 64-Digital MEMSplaced in a Sunflower Array

Combined visual light camera

Strong processor for onboard real-time processing

Frequency filtering

Sound classification

Event triggering available

dB values and sound intensity mapping

Ethernet network communications interface with installed 8-wire M12 Fieldbus or RJ45 connector

Ingress Protection IP54

Power over Ethernet (POE)

Option available for IO support via Fieldbus coupler

SoundMap™ Technology

By making use of strong SoundMap™ technology, the SV600 translates the sounds that it hears into a visual representation so that users can rapidly locate and measure problem regions. This offers facilities additional insightinto product quality or safety concerns, as well as the potential to rapidly detect changes throughout pipes, compressors, conveyors, pumpsand more.

Aside from 24/7 remote monitoring, the SV600 can also be integrated into factory systems smoothly and user-defined alarms can be fixed to alert users when sound signatures have altered, even in the parts of a user’s facility that are hard to reach.

By acting as an early warning system, facilities can constantly track equipment to improve performance, execute preventative maintenance or detect mechanical anomalies, like bearing wear, well before a failure takes place to keep processes up and running.

SV600 Payload for Spot^® from Boston Dynamics

At present, the SV600 Acoustic Imager could be utilized as a payload for Spot^® from Boston Dynamics. Spot automates sensing and inspection, captures limitless dataand can explore without boundaries, all while the SV600 allows users to constantly detect, locateand envision the unheard and unseen.

SV600 Fixed Acoustic Imager from Fluke Process InstrumentsPlay

Image Credit: Fluke Process Instruments EMEA

SV600 Fixed Acoustic Imager Payload for Boston Dynamics Spot®Play

Image Credit: Fluke Process Instruments EMEA
