Fluke 1630 Earth Ground Clamp Meter from Fluke Corporation

The clamp-on ground testing technique used by the Fluke 1630 simplifies ground loop testing and enables non-intrusive leakage current measurement. The compact and rugged design makes the Fluke 1630 easy to use in small places and harsh environments, while the ‘display hold’ and the continuity testing with an audible alarm function ensures convenience in use. The novel technique means that earth ground loop testing and continuity testing can be completed without breaking the circuit.

Features

A wide ground loop resistance range, from 0.025 Ù to1500 Ù, to satisfy all requirements

Large jaw opening of 35 mm (1.38 in) for tests on ground conductors and/or equipotential bus bars

Measurement of ground leakage current, from 0.2 mA to 1000 mA, without needing to disconnect - ideal for system troubleshooting

Wide ac current measurement range from 0.2 A to 30 A allows one instrument for multiple applications
