H-Model Ultraviolet Laser: High-Power, Compact UV-A Module
Daylight Solutions providesportable, high-power laser modules in the ultraviolet (UV-A) spectral range.A fiber-optic pigtailed package provides CW power levels up to 1 Watt at 375 nm, making beam delivery and system integration easier.
These lasers can also be used in pulsed or CW mode. Daylight has provided UV laser capabilities for applications that need high dependability in difficult situations by utilizing its experience in creating commercial devices for operation in hostile conditions.
Highlights
Features & Benefits:
UV-A output with high power
Fiber-optic beam delivery
Ruggedized to endure severe conditions
Fluorescence imaging
UV curing
Currency authentication
Optical communications
Applications:
Chemical and biological detection
Water purification
Disinfection
Skin treatment
Product Specifications
Source: DRS Daylight Solutions Inc.
| . | . |
|---|---|
| Center Wavelength Availability | 375 nm |
| Spatial Mode | Multimode (nominal) |
| Beam Divergence | < 7 mrad (full angle, 1/e2intensity width) |
| Fiber Cable Core Diameter | 50 µm |
| Fiber Cable Numerical Aperture | .22 |
| Pulse Repetition Frequency | CW to 10 kHz |
| Rise/Fall Time | < 200 ns |
| Compliance Voltage | < 18 VDC |
| Operating Current | 2 channels < 0.8 A per channel |
| Dimensions | 5.3 × 4.3 × 2.2 cm |
| Operating Range (Case Temp) | 20 – 30 °C |
