High-Performance Eddy-Current Displacement Sensor - ECL202 Series by Lion Precision
The Lion Precision ECL202 eddy-current displacement sensor provides highest precision with a digital core and push-button controls.
Key Features:
The product features of the ECL202 eddy-current displacement sensor are:
Linearity: ±0.2%
Resolution (typical):(Dependent on Probe and Range)
ECL202 Non-ferrous: 0.006% RMS
ECL202 Ferrous: 0.008% RMS
ECL202e: 0.2 µm RMS or higher
"Fine" ranges available for higher resolution
0-10 VDC output
15 kHz bandwidth
Push-button switch threshold (setpoint)
Push-button offset
Remote offset and threshold activation
Range indicating LEDs
Probes can be ordered as vacuum compatible
User-selectable bandwidth/resolution 100 Hz, 1 kHz, 10 kHz, 15 kHz
CE Compliant.
Specifications
The specifications of the ECL202 eddy-current displacement sensor are:
| Resolution:RMS, TypicalDependent on probe and range. | ECL202 | 0.006% (Non-ferrous)0.008% (Ferrous) |
| ECL202e | Greater of 0.2 µm or0.006% (Non-ferrous)0.008% (Ferrous) | |
| Linearity | ±0.2% of Range | |
| Error Band | ±0.4% of Range | |
| Bandwidth | Selectable: 100 Hz, 1 kHz, 10 kHz, 15 kHz | |
| Driver Temperature Drift(15°C-50°C) Typical. See Probe/Range chart for details. | ||
| Driver Temperature Drift(15°C-50°C)Typical. See Probe/Range chart for details. | ±0.01% F.S./°C | |
| Probe Temperature Drift(15°C-65°C, except where noted)Typical. See Probe/Range chart for details. | ±0.01% F.S./°C | |
| Analog Output | 0-10 VDC, 0 Ù, 15 mA | |
| Switched Output | 30 VAC/60 VDC/100 mA | |
| Input Power | 12-24 VDC1.9 W | |
| Driver Operating Environment | 4°C-50°CIP40 | |
| Probe Operating EnvironmentStandard Probes come with PUR (Polyurethane) jacketed cables. High Temperature Probes have FEP jackets.Other temperature ranges may be possible.Standard Probes: IP67High Temperature Probes: IP63 | U3 Probe | Standard Probe (PUR Cable):-25°C to +125°C(Available with optional FEP cable)High Temperature Version Not Available |
| U5-18 Probes | Standard Probes:-25°C to +125°CHigh Temperature Probes:-25°C to +200°C | |
| U25-50 Probes | Standard Probes:-25°C to +125°CHigh Temperature Probes:-25°C to +175°C | |
