IMSL Submersible Level Transmitter
The IMSL Submersible level transmitter has been specifically developed for use in constant submersion in water, oil, and other liquids and non-aggressive chemicals. The transmitter is equipped with a stainless steel silicon sensor, thus making it precise, stable, and repeatable with excellent thermal performance. It employs the advanced piezo-resistive media isolated silicon sensing technology and provides superior resolution and stability needed for use in rivers and reservoir measurement.
The submersible level transmitter is enclosed in a 316L stainless steel housing and is a suitable option for consistent and repeatable hydrostatic level measurement. Each device is calibrated and temperature compensated and comes with a calibration certificate and traceable serial number. A microprocessor-based amplifier is integrated in the device that eliminates adjusting pots and makes the transmitter extremely stable.
Key Features
The product features of the IMSL Submersible level transmitter are:
Excellent resolution, thermal performance, stability and repeatability
Reliable and repeatable hydrostatic level measurement
Microprocessor-based amplifier eliminates adjusting pots
Temperature-compensated and calibrated
316L stainless steel housing
Comes with calibration certificate and traceable serial number
Specifications
The specifications of the IMSL Submersible level transmitter are provided in the table below: :
| Minimum level range: | 0.5mWG |
| Maximum level range: | 100mWG |
| Reference: | Gauge or Absolute |
| Output: | mV, volts, 4-20mA |
| Supply Voltage: | 2-12V dc, 5V dc, 9 -32V dc |
| Cable sheath material: | PVC, PUR, FEP, TPE |
| Accuracy: | <±0.1% FS BFSL (<±0.06% optional) |
| Temperature Range: | -20 to +60°C non-freezing |
| Optional Extras: | Measurement range, output and supply versions, cable type and accuracy |
