M-20iA Cutting Robotics from FANUC Robotics America, Inc.

The evolutionary design of the M-20iA solves two of the oldest problems for industrial robots. The first issue is the time it takes to engineer the robot dressout and the second is the down-time caused when the dressout is disrupted by contact with plant equipment. The innovative M-20iA solves these issues with a hollow upper arm and wrist. This unique design permits the utilities to be neatly contained within the arm, eliminating dress out issues like snagging, tearing and rubbing. A shelf with ample space on the back of the upper arm completes the package by allowing peripheral equipment to be easily mounted. The hollow arm and wrist together with the shelf greatly simplifies the integration engineers job.

To complement the built-in vision, the M-20iA has an integrated vision cable from the J1 base to J3 interface panel. This makes the addition of vision to the robot application much easier. This design is also a great benefit for offline simulations because the dress out and control boxes can all be designed to fit with in the confined space of the robot arm and eliminates the guess work of dress out interference.

This exceptional design comes with out sacrificing any of the robot’s performance specifications. In fact this robot is an industry leader in payload, reach and axes speed. Add this to the industry leader in reliability and this robot is the perfect solution for your robotic application.

M-20iA Series, the solution for:

Assembly

Dispensing

Material handling

Machine load/unload

Material removal

Waterjet cutting

Laser cutting

Machine tending

Picking and packing

Testing and sampling

Features & Benefits

6 degrees of freedom

± 0.10 mm repeatability

20 kg payload at wrist

Large wrist moments and inertias for real-world EOATs and workpieces

Supplementary payload mount on J3 casting

Pneumatic and electrical (8 DI/8 DO) connections for EOAT on J3

2D vision cables from J1 to J3 as a standard option
