NovaSensor NPA Series - Surface Mount Pressure Sensors

The NovaSensor NPA Series of Surface-Mount Pressure Sensors from Amphenol Advanced Sensor is available in a compact size and provides an economical solution for applications requiring calibrated performance.

The NPA Series is housed in a SOIC14 pin surface mount and comes in gauge, absolute, and differential pressure ranges with mV or amplified digital or analog outputs. The sensor is intended for printed circuit board mounting and supplied in reel and tape form to streamline manufacturing handling.

Features

Absolute, gauge, differential, and low pressure

Can be mounted on a surface

2"H₂O to 30 PSI full scale

On-chip temperature sensor available in digital mode

Output options — digital serial (14 bit), amplified analog, digital I2C, and uncalibrated mV

Operating temperature range of −40 °C to 125 °C

Up to 60 psi proof pressure

Total error band < ±1.5% FSO; ±2.5% FSO at 2"H₂O
