Produce the Exact Images You Need and Accelerate Your Application Development: Blackfly S USB3
The Blackfly® S from FLIR Systems takes advantage of the industry’s latest sensors in an ice-cube form factor.
Packed with robust features, the camera allows users to easily produce their preferred, exact images and expedite their application development. This involves both automatic control and accurate manual control across on-camera pre-processing and image capture. The Blackfly® S comes in USB3, GigE, casedand board-level versions.
The Exact Images Needed by Users
The Blackfly® S camera offers users a choice of high sensitivity BSI sensors, polarizationand CMOS global shutter. Color transformation tools also guarantee true-to-life color. Advanced auto-algorithms or accurate manual control are available in the camera.
Develop Once, Deploy Anywhere
The Blackfly® S camera has been designed to support a broad range of host system hardware architectures and operating systems. Users can simply switch to board-level models for embedded systems. Streamlined product iteration with constant form factor is ensured across different sensor sizes.
Accelerate Application Development
The Blackfly® S camera can be used with third-party hardware and software. Rugged strong on-camera features minimize code-writing tasks. Users can quickly construct custom applications with descriptive API logging and a rich sample code.
FLIR Blackfly S Family: Develop Once, Deploy Everywhere
Video Credit: FLIR Systems
Specifications
Source:FLIR Systems
| Overview | |
|---|---|
| ADC | 8-bit, 10-bit, 12-bit |
| Chroma | Color |
| Frame Rate | 522 |
| Lens Mount | CS-mount |
| Megapixels | 0.4 |
| Part Number | BFS-U3-04S2C-CS |
| Pixel Size | 6.9 |
| Readout Method | Global shutter |
| Required Accessories | Lens, Cable, Host Adapter (USB 3.1 Gen 1), Tripod Mount Adapter (ACC-01-0003) |
| Resolution | 720 × 540 |
| Sensor Format | 1/2.9" |
| Sensor Name | Sony IMX287 |
| Sensor Type | CMOS |
| Compliance and Certifications | |
| Compliance | CE, FCC, KCC, RoHS. The ECCN for this product is: EAR099. |
| Machine Vision Standard | USB3 Vision v1.0 |
| Warranty | 3 years |
| Environmental | |
| Operating Humidity | 20 to 80% (no condensation) |
| Operating Temperature | 0° to 50°C |
| Storage Humidity | 30 to 95% (no condensation) |
| Storage Temperature | -30° to 60°C |
| Features | |
| Acquisition Modes | Continuous Single Frame Multi Frame |
| Exposure Range | 4 µs to 30 seconds |
| Flash Memory | 6 MB non-volatile memory |
| Gain Range | 0 db to 47 dB |
| Image Buffer | 240 MB |
| Image Processing | Color correction matrix, gamma, lookup table, saturation and sharpness |
| Partial Image Modes | Pixel binning, decimation, ROI |
| User Sets | 2 user configuration sets for custom camera settings |
| Performance | |
| Absolute Sensitivity Threshold (y) | 7.55 |
| Dynamic Range dB | 74.35 |
| Quantum Efficiency Blue | 49.86 (460 nm) |
| Quantum Efficiency Green | 56.96 (530 nm) |
| Quantum Efficiency Red | 45.11 (625 nm) |
| Saturation Capacity (e-) | 22436 |
| Temporal Dark Noise (e-) | 3.80 |
| Physical | |
| Auxiliary Output | 3.3 V, 120 mA maximum |
| Dimensions [W x H x L] | 29 mm × 29 mm × 30 mm |
| Interface | USB 3.1 Gen 1 |
| Mass | 36 grams |
| Non-isolated I/O Ports | 1 bi-directional, 1 input |
| Opto-isolated I/O Ports | 1 input, 1 output |
| Power | |
| Power Consumption | 3 W |
| Power Requirements | 8-24 V via GPIO or 5 V via USB3 |
| Recommended System Configuration | |
| CPU | 3.1 GHz or equivalent CPU |
| Hard Drive | 200 MB hard drive space |
| Operating System | Windows or Linux (32–bit or 64–bit) |
| Port | USB 3 Port |
| RAM | 2 GB RAM or more |
Accessories
Cables
USB 3.1 locking cable (cast metal connectors)
USB 3.1 locking cable
GPIO Cables
Hirose HR10 (6 Pin) GPIO cable
Lenses
Fujinon 12.5-mm 2/3″ C-mount lens
Host Adapters
USB 3.1 Host Controller Card
Optical Mounts
CS- to C-mount 5-mm spacer adapter
Tripod Adapters
Tripod adapter for BFS (30mm), BFLY, CMLN, CM3, FFMV, FL2, FL3and FMVU
Tripod adapter for 39-mm Blackfly® S Models
Connectors
Hirose HR10 Circular GPIO connector
