Compact, 3-Channel Photodiode, RGB Color Sensor

上海仪舶实验室自动化 25-08-20 14:10:33

Compact, 3-Channel Photodiode, RGB Color Sensor

Hamamatsu’s S10917-35GT RGB color sensor is a compact device integrated in a small and thin package. It includes a 3-channel photodiode mounted in a single package, and is sensitive to blue (λ=390 to 530 nm), green (λ=470 to 600 nm), and red (λ=590 to 680 nm) light. The photosensitive area includes an infrared-cut filter.

The S10917-35GT color sensor attains excellent cost performance, and is perfect for tracking the brightness of a RGB-LED backlight LCD in portable devices like cellular phones.

Download the Brochure for More Information

Key Features

3-channel (RGB) Si photodiode

Infrared-cut filter formed on photosensitive area

Photosensitive area: 1 ×1 mm/3-segment (RGB)

Superior cost performance

Small, thin package: 3.0 × 1.6 × 1.0 mm

Surface mount type

RoHS-compatible

Applications

RGB-LED type LCD backlight monitors

Color detection

Mobile or portable equipment

Detectors for a wide range of light sources
