Compact VEGAPULS 31 for Continuous Level Measurement
VEGAPULS 31 is the perfect sensor solution for non-contact level measurement of liquids and bulk solids in simple applications.
4-20 mA/HART output
Measuring range up to 15 m
Accuracy ±2 mm
Ex approval
On-site display
Three-button operation
It is ideal for use in storage tanks with acids, water treatment, lyes, and additives in all industrial areas or for quantifying levels in plastic tanks from the outside via the tank wall. As far as bulk solids are concerned, the sensors are utilized in open containers or small bulk solids silos.
Benefit
Exact measurement results independent of medium properties and process conditions
Maintenance-free operation thanks to non-contact 80 GHz radar technology
On-site display for straightforward level control
Applications
Hydraulic oil station: Level and measurement in the hydraulic oil station
Intermediate bulk containers: Level measurement can be performed in IBC containers
Storage tank for flocculant: Level measurement and point level detection in flocculant storage tanks
Wet deslagger: Level measurement in the wet deslagger
Technical Specifications
Source: VEGA Grieshaber KG
| . | . |
|---|---|
| Measuring range – Distance | 15 m[Meter-Foot] |
| Process temperature | -40 ... 80 °C[°C-°F] |
| Process pressure | -1 ... 3 bar[Bar-kPa-psi] |
| Accuracy | ± 2 mm |
| Frequency | 80 GHz |
| Beam angle | 8° |
| Materials, wetted parts | PVDF |
| Threaded connection | G1½, 1½ NPT, R1½ |
| Seal material | FKM |
| Housing material | Plastic |
| Protection rating | IP66/IP67, Type 4X |
| Output | 4…20mA/HART |
| Ambient temperature | -40 ... 70 °C |
