Cubic Particulate Matter Sensing Solutions for Environmental Air Quality Monitoring

Integrated Module | AM1002 PM1.0+PM2.5+PM10+VOC+RH&T

The compact AM1002 integrated air quality sensor module provides real-time measurements of PM1.0, PM2.5, PM10, VOC and RH&T concentrations.

Particle concentration is detected by leveraging the power of laser scattering technology, with a real-time output of PM1.0, PM2.5 and PM10 provided in μg/m³ via a sophisticated mathematical algorithm and scientific calibration.

The instrument also features a highly sensitive MOX type VOC sensor.

Image Credit:Cubic Sensor and Instrument Co. Ltd

Integrated Air Quality Sensor Module | AM1009

The AM1009 integrated air quality sensor module provides real-time measurement of PM1.0, PM2.5, PM10, VOC, NO₂ and RH&T concentrations.

Laser scattering technology enables the real-time output of particle concentrations, with PM1.0, PM2.5 and PM10 reported in μg/m³ thanks to robust scientific calibration and an advanced mathematical algorithm.

The instrument can also measure VOC and NO₂ concentrations simultaneously thanks to its combined MOX sensor.

Image Credit:Cubic Sensor and Instrument Co. Ltd

Anti-Dust Laser Particle Sensor | PM2016

The PM2016 anti-dust laser particle sensor offers PM1.0, PM2.5 and PM10 output. It can accurately measure and calculate the suspended particle number within unit volume in air.

Particle mass concentration is directly reported in μg/m³ via a sophisticated mathematical algorithm and scientific calibration.

Image Credit:Cubic Sensor and Instrument Co. Ltd

Laser Particle Sensor | PM2008-API

The PM2008-API laser particle sensor module is ultra-thin (12 mm) and features robust metal shielding.

Laser scattering technology allows the sensor to detect particle concentration sizes in air between 0.3 μm and 10 μm. Real-time output of PM1.0, PM2.5 and PM10 is reported in μg/m³ via a mathematical algorithm and scientific calibration.

Image Credit:Cubic Sensor and Instrument Co. Ltd

Laser Particle Sensor with Screw Hole | PM2008M-M

The PM2008M-M laser particle sensor module with screw hole design offers advanced laser scattering technology, an ultra-thin design (12 mm) and sturdy metal shielding.

It is able to detect particle concentration sizes in air between 0.3 μm and 10 μm and employs mathematical algorithms and scientific calibration to provide real-time output of PM1.0, PM2.5 and PM10 in terms of μg/m³.

Image Credit:Cubic Sensor and Instrument Co. Ltd

Small Size Laser Particle Sensor | PM2012SE-A/PM2012SE-B

The extremely compact PM2012 laser particle sensor module is built using laser scattering technology. It can detect particle concentration sizes between 0.3 μm and 10 μm in air and utilizes comprehensive scientific calibration and a mathematical algorithm to deliver real-time output of PM1.0, PM2.5 and PM10 in μg/m³.

Image Credit:Cubic Sensor and Instrument Co. Ltd

Anti-Dust Laser Particle Sensor | PM2009L

The PM2009L laser particle sensor module is based on laser scattering technology and features a specifically designed anti-dust structure.

It is capable of detecting particle concentration sizes between 0.3 μm and 10 μm in air while offering real-time output of PM1.0, PM2.5 and PM10 as μg/m³ thanks to its use of a mathematical algorithm and scientific calibration.

Image Credit:Cubic Sensor and Instrument Co. Ltd

LED Particle Sensor | PM1003

The PM1003 infrared (LED) particle sensor offers real-time output of PM2.5. It has been specifically designed to detect and report trending variations in particle concentration size between 1.0 μm and 10 μm.

The sensor can measure dust concentration in air via detection of scattered light intensity, outputting this as a real-time concentration via a mathematical algorithm and scientific calibration.

Image Credit:Cubic Sensor and Instrument Co. Ltd

LED Particle Sensor with Dust Correction | PM1006K

The PM1006K infrared (LED) particle sensor provides real-time output of PM2.5 while leveraging powerful dust deposition self-correction technology.

It can measure dust concentration in air through the detection of scattered light intensity before outputting concentration measurements in real-time via a mathematical algorithm and scientific calibration.

Image Credit:Cubic Sensor and Instrument Co. Ltd

Outdoor Laser Particle Sensor | PM3006S/Heater

The PM3006S outdoor particle sensor is a linear laser light source-based module that uses light scattering technology. Its use of a high quality laser diode and fan allows the PM3006S to be employed in working temperatures of -30 °C to 70 °C.

This sensor is able to measure the quantity per unit volume of various particle sizes before outputting particle mass concentrations of PM1.0, PM2.5, PM10 in μg/m³ via scientific calibration and a mathematical algorithm.

Image Credit:Cubic Sensor and Instrument Co. Ltd

Online Outdoor Air Quality Monitoring Device | OPM-6303

The OPM-6303 online outdoor air quality monitoring device employs a powerful pump-suction sampling method coupled with a robust, reliable metal structure.

The instrument employs a novel intelligent auto particle identification (API) technology, maintaining accurate measurements in a range of dust source scenarios.

It can consistently and accurately output PM2.5, PM10 or TSP mass concentrations and features a built-in pre-treatment device and flow monitoring sensor specifically designed to facilitate outdoor use in a range of conditions.

Image Credit:Cubic Sensor and Instrument Co. Ltd

Optical Particle Counter Module | PM5000S/7500H-OPC

The PM5000S optical particle counter module employs laser scattering technology to accurately detect and calculate the number of different sizes of suspended particles in air per unit volume.

The instrument’s built-in intelligent identification technology allows it to adjust to different air or dust sources, automatically identifying dust sources and ambient air to maintain accurate measurement.

It is also able to simultaneously output particle quantity in six channels: 0.3 μm, 0.5 μm, 1.0 μm, 2.5 μm, 5.0 μm and 10 μm (PCS/L).

Image Credit:Cubic Sensor and Instrument Co. Ltd

Online Particle Counter Monitoring Device | OPC-6303P

The OPC-6303P online particle counter monitoring device utilizes a combination of laser scattering technology, a stable pump-suction sampling method and patented API technology to accurately detect and calculate the number of suspended particles with various particle sizes in clean room settings.

The OPC-6303P can simultaneously output particle quantity in six channels: 0.3 μm, 0.5 μm, 1.0 μm, 2.5 μm, 5.0 μm and 10 μm (PCS/L).

Image Credit:Cubic Sensor and Instrument Co. Ltd

Automotive Particulate Matter Sensor | APMS-3302

The APMS-3302 automotive particulate matter sensor is a laser particle sensor module that has been specifically designed for automotive applications. It is able to accurately measure PM2.5 concentration, directly outputting this in μg/m³ through the use of a mathematical algorithm and scientific calibration.

Image Credit:Cubic Sensor and Instrument Co. Ltd

Automotive Particulate Matter Sensor | APMS-5000

The APMS-5000 automotive particulate matter sensor is an advanced laser particle sensor module designed for automotive applications. The sensor can accurately measure PM2.5 concentration before using a mathematical algorithm and scientific calibration to directly output this in μg/m³.

Image Credit:Cubic Sensor and Instrument Co. Ltd
