Gaslab Fixed Multi-Gas Detector

The Fixed Multi-Gas Detector has been developed to safeguard individuals near toxic, combustible, and hazardous gases or oxygen in commercial and industrial settings. It can activate alarm relays, display real-time gas measurements, and integrate with any Building Maintenance System (BMS).

The Gaslab Fixed Multi-Gas Detector can monitor up to 1-3 gases, including ammonia, carbon dioxide, carbon monoxide, hydrogen, and oxygen. Equipped with three configurable relays and audible/visual alarms, the MSC2 meets most safety code requirements and industry standards.

Features

Modular, user-friendly design

1-3 gas sensor capacity

Three configurable relays

A maximum of two sensors from the SC2 series can be used; up to threemay be analog sensors with 4-20 mA output signals

Customizable configurations based on application and location

Warning buzzer/LED alarm with fault and operation options

Compatible with various BMS

DGC-06 or Modbus protocol support

Operating voltage options: 100-240 VAC or 24 VDC

Specifications

Gas Type: Dependent upon gas sensors selected

Measurement Range: Dependent upon gas sensors selected

Installation: Wall Mounted

Housing Type C/E: Polycarbonate

Storage Temperature: -4 °F to 149 °F (0° to 20 °C)

Knockouts for Cable Entry: Standard 6× M20/25

Ingress Protection: IP65

Humidity Range: 15-90 % RH non-condensing

Temperature Range: -13 °F to 140 °F (-30 °C to 50 °C)

Alarm Relay (3): 5 A Dry Contact Configurable

Power Supply: 100-240 VAC or 24 VDC

Power Consumption: 24 V DC | Max. 60 mA (1.5 VA), w/ sensor, w/o WAO

Transistor Output (2): 24 V DC/0.1 A

Analog Input (2/3): 4-20 mA, overload and short-circuit proof, input resistance 130 proportional, overload and short-circuit proof, load ≤ 500 4–20 mA = measuring range

Analog Output Signal (1):

20–21.2 mA = tolerable over range

2.4–< 4 mA = tolerable under range

≤ 2,0 mA = fault

≥ 21,2 mA= error over range

Dimensions: 5.12 × 5.12 × 2.95 in. (130 × 130 × 75 mm)

Weight: 1.32 lbs. (0.6 kg)

Warranty

1 year

Accessories

Options

SC2-E1110-A-P-00 | CO Digital Sensor for MSC2

SC2-E1195-A2-P-00 | O₂ Digital Sensor for MSC2

SC2-E1130-B-P-00 | NO₂ Digital Sensor for MSC2

SC2-E1194-A-P-00 | H₂ Digital Sensor for MSC2

SC2-I464-B-P-00 | CO₂ Digital Sensor for MSC2

SC2-P3400-A-P-00 | CH₄ Digital Sensor for MSC2

SC2-E1129-C-P-00 | NO₂ Digital Sensor for MSC2

SC2-P3480-A-P-00 | C₃H₈ Digital Sensor for MSC2
