The Norbond® A7600 Series from Saint-Gobain® is a high-performance double-sided acrylic foam tape with exceptional viscoelastic and adhesive capabilities.The tape offers good bonding performance for various industrial applications, both indoors and out.
A7600 has been engineered to provide strong, long-lasting adhesion, exceeding industry standards for shear strength and bonding to surfaces with high surface energy, even at higher temperatures.
Download the Brochure for More Information
A7600 is specifically designed to provide the following features:
Enhanced adhesion performance in the short term to facilitate field assembly
Excellent tensile, peel, and dynamic shear adhesion performance
Superior conformability and resistance to dynamic stress loads
Long-lasting adhesion at higher temperature
Stress and shock absorption
Available Sizes
Standard thickness: 1.1 mm (.043”)
Jumbo roll size: 800 mm (31.5”) × 300 m (984 ft)
Master roll size: 800 mm (31.5”) × 33 m (108 ft)
Applications
Changing the permanent attaching methods (liquid adhesives, rivets, and welds) employed in common industrial applications
Bus, truck, and trailer skin bonding
Bus, truck, and trailer roof bow bonding

Image Credit: Saint-Gobain Tape Solutions
Download the Brochure for More Information
Norbond A7600—Properties
Performance tests are conducted using common test processes. The specified values are standard and should not be utilized for the purpose of specification.
Source: Saint-Gobain Tape Solutions
| Thickness | 90° Peel Adhesion1 | T-Block2 | DynamicShear3 | StaticShear4 | ServiceTemperature | |
|---|---|---|---|---|---|---|
| 20 minutedwell | 3-daydwell | |||||
| WithoutLiner | StainlessSteel | StainlessSteel | Aluminum | StainlessSteel | StainlessSteel | |
| mm(in.) | N/cm(lb/in) | N/cm(lb/in) | N/cm2(lb/in2) | N/cm2(lb/in2) | 7 days/1 kg | |
| 1.1(.043) | 34(19) | 39(22) | 57(83) | 54(79) | Pass andExceeds | -35 °C to 93 °C(-30 °F to 200 °F) |
1 Based on ASTM D33302 Based on ASTM D897 3 Based on ASTM D10024 Based on ASTM D3654
Options (Subject to Minimum Order Requirements)
Liner: Available in coated release liner, with low liner release values for quick and easy removal.
Important Instructions
It is highly advised to test this product under specific application parameters before commercial usage, as Saint-Gobain is unable to forecast or control every possible use.
Surfaces must be clean and devoid of dust, oil, moisture, grease, and dirt. Isopropyl alcohol is good for cleaning surfaces.
Apply an even pressure of 103 kPa (15 psi) to ensure good contact between the tape and the bonded material. The application temperature should be between 16 and 52 °C (60 and 125 °F). Applying these tapes at temperatures below 16 °C (60 °F) is not recommended since the adhesive does not flow and can result in poor bonding
The adhesion between the substrate and the tape strengthens over time, often reaching its final bond strength in 72 hours. Heat the product over 40 °C (105 °F) to expedite the adhesion process.
Shelf Life
This product has a shelf life of 24 months from the production date, provided it is stored in its original packaging at 50% relative humidity and temperatures up to 21 °C (70 °F).
Download the Brochure for More Information
