Ladybug5+: Spherical 360° Imaging and Accuracy
FLIR makes spherical video a reality by providing affordable hardware and software packages that deliver high-resolution, 360° visual coverage. It is capable of obtaining an impressive 8k30 or 4k60 of content and an accuracy level of 2 mm at 10 m.
The Ladybug5+ systems perform the image acquisition, processing, stitching, and correction necessary to integrate multiple camera images into full-resolution digital spherical and panoramic videos, live. The quality and flexibility of spherical video data make the medium ideal for applications requiring synchronization of video images including terrain mapping, building management, news, event and sports coverage, entertainment, and virtual reality.
Specifications
Source: FLIR Systems
| Overview | |
|---|---|
| ADC | 12-bit |
| Chroma | Color |
| Color | Anodized Black |
| Field of View | 90% of full sphere |
| Frame Rate | 14.5 |
| Megapixels | 30 |
| Part Number | LD5P-U3-51S5C-B |
| Pixel Size | 3.45 |
| Readout Method | Global shutter |
| Resolution | 2048 × 2464 |
| Sensor Format | 2/3" |
| Sensor Name | Sony IMX264 |
| Sensor Type | CMOS |
| Compliance and Certifications | |
| Compliance | CE, FCC, KCC, RoHS. The ECCN for this product is: EAR099. |
| Machine Vision Standard | IIDC v1.32 |
| Warranty | 2 years |
| Environmental | |
| Environmental Protection | IP65 |
| Operating Humidity | 20 to 80% (no condensation) |
| Operating Temperature | -20° to 50°C |
| Storage Humidity | 20 to 95% (no condensation) |
| Storage Temperature | -30° to 60°C |
| Features | |
| Exposure Range | 0.02 ms to 2 seconds |
| Flash Memory | 1 MB non-volatile memory |
| Gain Range | 0 dB to 18 dB |
| Image Processing | Shutter, gain, white balance, gamma and JPEG compression, are programmable via software |
| Trigger Modes | Standard, skip frames, overlapped, multi-shot |
| User Sets | 2 memory channels for custom camera settings |
| Imaging | |
| Focus Distance | ~200 cm. Objects have an acceptable sharpness from ~60 cm to infinity |
| Optics | 6 high quality 4.4 mm focal length lenses |
| Spherical Distance | Calibrated from 2 m to infinity |
| Performance | |
| Dynamic Range dB | 70 |
| Temporal Dark Noise (e-) | 2.3 |
| Physical | |
| Auxiliary Output | 3.3 V, 150 mA maximum |
| Interface | USB 3.1 Gen 1 |
| Mass | 3.0 kg |
| Non-isolated I/O Ports | 2 bi-directional |
| Opto-isolated I/O Ports | 1 input, 1 output |
| Power | |
| Power Consumption | 13 W |
| Power Requirements | 12-24 V |
| Recommended System Configuration | |
| CPU | 3.1 GHz Dual / Quad Core CPU |
| Dimensions (Diameter x Height) | 197 mm × 160 mm |
| Operating System | Windows 7, 8 or 10, 64-bit |
| Port | USB 3 Port |
| RAM | 8 GB RAM or more |
| Video Card | NVIDIA Video Card 512 mb |
Accessories
Cables
USB 3.1 Locking Cable (cast metal connectors)
USB 3.1 Locking Cable
Hirose LF Connector
Host Adapters
USB 3.1 Host Controller Card
Hubs and Repeaters
USB 3.1 Hub
