The Quartet Carrier Board for TX2 from FLIR Systems allows the easy integration of up to four USB3 machine vision cameras at full bandwidth. Thanks to the Nvidia Jetson deep learning hardware accelerator, it is possible to set up a complete decision-making system on a single compact board. The fully integrated SOM design of the custom carrier board avoids the need for peripheral hardware and host systems, thereby optimizing the size and cost.
Stream 4 machine vision cameras at full bandwidth using Teledyne FLIR Quartet TX2 Embedded Solution
Video Credit: FLIR Systems
Features
Turnkey Solution: Run up to Four Cameras Simultaneously
The Quartet integrates up to four machine vision cameras simultaneously through its 4 x USB3 TF38 connectors, pre-integrated Spinnaker SDKand the NVIDIA Jetson TX2 module.
Minimize System Footprint
The fully integrated SOM is designed to avoid the need for peripheral hardware and host systems. A powerful single-board computer (SBC) has an extremely compact footprint, meaning that it can easily be integrated into systems constrained by space by combining power and data transmission over a single cable.
Powerful and Flexible Hardware
Users can choose from three different systems based on their needs. There are two options available with the module pre-installed with the FLIR Spinnaker SDK, which enables plug-and-play compatibility with FLIR Blackfly S USB3 machine vision cameras. Users can also choose the option to purchase only the carrier board and build their own system.
Specifications
Source: FLIR Systems
| Overview | |
|---|---|
| Display | HDMI Type A x 1 |
| Other | |
| Expansion | SATA connector x1Fan connector x1 |
| Physical | |
| Dimensions | 138 mm x 92 mm x 18.2 mm |
| Mass | 95 g |
| Operating Temperature | -4 °F ~ 140 °F (-20 °C ~ 60 °C)* w/0.5 m/s air-flow |
| Part Number | ACC-01-6003 |
| Storage Humidity | 5~ 95% @ 40 °C, non-condensing |
| Storage Temperature | -40 °F ~ 158 °F (-40 °C ~ 70 °C) |
| Power | |
| Input Power | 10~24 Vdc with 2-pin terminal block |
| Input_Output | USB 3.0 x 4 (TF-38)USB 2.0 type A x 1USB 3.0 type A x 1Power switch x 1 with LEDMicro SD slot x 1OTG x 1 |
Accessories
Cables:
30 mm FPC cable for board level Blackfly S
15 cm FPC cable for board level Blackfly S
30 cm FPC cable for board level Blackfly S
