Transfer Speeds up to 10 Gbit/s Enabling the Capture of 4K Resolution: Oryx 10GigE
The award-winning Oryx 10GigE camera series from FLIR Systems allows designers to manipulate the advanced sensors by supporting transfer speeds of up to 10 Gbit/second and helps capture 4K resolution, 12-bit images at more than 60 FPS.
The 10GBASE-T interface from Oryx is an established and extensively deployed standard that offers consistent image transfer at cable lengths of more than 50 m on low cost CAT6A, or greater than 30 m on CAT5e.
On-camera features, such as IEEE1588 clock synchronization and complete compatibility with well-known third-party software that supports GigE Vision, provide system designers with the required tools to rapidly develop innovative solutions.
High Speed 10GigE Interface
Transfer speed of 10 Gbit/second supports 4K60 (12-bit), and long cable lengths support CAT5e and CAT6A cables.
Reliability and Simplicity
The huge 10GBASE-T install base supports the preferred consumer ecosystem. It is compatible with GigE Vision, and the packet resend function enables consistent image transmission.
Flexibility for Integrators
The IEEE1588 Clock Synchronization ensures accurate timing across various devices. Gamma, Color Correction Matrix, Saturationand Sharpness decrease host-side processing needs.
FLIR Oryx 10GigE Camera: First Look
Video Credit: FLIR Systems
Specifications
Source: FLIR Systems
| Overview | |
|---|---|
| ADC | 8-bit, 10-bit, 12-bit |
| Chroma | Color |
| Frame Rate | 216 |
| Lens Mount | C-mount |
| Megapixels | 3.2 |
| Part Number | ORX-10GS-32S4C-C |
| Pixel Size | 3.45 |
| Readout Method | Global shutter |
| Required Accessories | Lens, Cable, Host Adapter (10GigE), Power Supply (ACC-01-9013 ) |
| Resolution | 2048 × 1536 |
| Sensor Format | 1/1.8" |
| Sensor Name | Sony IMX252 |
| Sensor Type | CMOS |
| Compliance and Certifications | |
| Compliance | CE, FCC, KCC, RoHS, REACH. The ECCN for this product is: EAR099. |
| Machine Vision Standard | GigE Vision v1.2 |
| Warranty | 3 years |
| Environmental | |
| Operating Humidity | 20 to 80% (no condensation) |
| Operating Temperature | 0° to 70°C (case) |
| Storage Humidity | 20 to 95% (no condensation) |
| Storage Temperature | -30° to 60°C (ambient) |
| Features | |
| Acquisition Modes | Continuous Single Frame Multi Frame |
| Exposure Range | 17 µs to 30 seconds |
| Flash Memory | 4 MB non-volatile memory |
| Gain Range | 0 db to 47 dB |
| Image Buffer | 240 MB |
| Image Processing | Color correction matrix, gamma, lookup table, saturation and sharpness |
| Partial Image Modes | Pixel binning, decimation, ROI |
| Serial Port | 1 (over non-isolated I/O) |
| User Sets | 2 user configuration sets for custom camera settings |
| Performance | |
| Absolute Sensitivity Threshold (y) | 4.67 |
| Dynamic Range dB | 71.89 |
| Quantum Efficiency Blue | 48 (470 nm) |
| Quantum Efficiency Green | 59 (525 nm) |
| Quantum Efficiency Red | 45 (630 nm) |
| Saturation Capacity (e-) | 10787 |
| Temporal Dark Noise (e-) | 2.24 |
| Physical | |
| Auxiliary Output | 3.3 V, 120 mA maximum |
| Dimensions [W x H x L] | 60 mm × 60 mm × 64 mm |
| Interface | 10 GigE |
| Mass | 386 grams |
| Non-isolated I/O Ports | 1 bi-directional, 1 input |
| Opto-isolated I/O Ports | 2 input, 2 output |
| Power | |
| Power Consumption | 11.8 W (11.3 W nominal); GPIO power only |
| Power Requirements | 12-24 V, via GPIO interface |
| Recommended System Configuration | |
| CPU | 4th Generation Intel Core i7 (or newer) |
| Hard Drive | 200 MB hard drive space |
| Operating System | Windows or Linux (32–bit or 64–bit) |
| Port | 10GBASE–T Ethernet Port |
| Power Sourcing Equipment | Camera Power Supply (12 V 1.5 A, 12–pin Hirose) |
| RAM | 8 GB RAM or more (dual channel) |
Accessories
Cables
GigE locking cable
GigE cable
GPIO Cables
Hirose HR10 (12-pin) circular connector
Lenses
Fujinon 12.5-mm 2/3″ C-mount lens
Tamron 16-mm 2/3″ C-mount lens
Fujinon 25-mm 2/3″ C-mount lens
Tamron 25-mm 2/3″ C-mount lens
Host Adapters
10 GigE Network Interface Cards
Power Supplies
Includes 12 V power supply with a 12-pin HR10 connector
Optical Mounts
Oryx F mount
