Based on our 10 MW modular deign, each state-of-the-artPSM Series electrolysers unithouses eight 1.25 MW PEM stacks and is designed to offer guaranteed, repeatable performance.The units can be sited outside and networked together to form electrolyser plants at scale.Each module can produce up to 2,020 Nm3/h or 4,300 k/24 h of hydrogen gas at 99+% purity.
Features
Containerized electrolyser stack module – easy integration into large plants
Cost-effective hydrogen supply – tracks electric costs
Proton Exchange Membrane (PEM) electrolyte – no caustic chemicals
Outdoor placement– eliminates the need for a building and reduces construction cost
Pre-integrated stacks – reduce installation time and risk
Pre-tested and at factory assembled – helps maintain qualitycontrol
Specifications
Source: Nel Hydrogen
| Specifications | PSM | |||
|---|---|---|---|---|
| Net Production Rate | 2,020 Nm³/h –4,300 kg/24 h | |||
| Turndown Range | 10 to 100% | |||
| Power Consumption at Stack at 100% Capacity1 | 4.7kWh/Nm³ – 53.2 kWh/kg | |||
| Purity | 99+%, saturated gas with liquid water | |||
| O2-Content in H2 | < 1 ppm v | |||
| H2O-Content in H2 | < 2 ppm v | |||
| Delivery Pressure | 30 barg (435 psig) | |||
| Dimensions W x D x H, without vent stack | 13.4 m x 2.4 m x 2.9 m (44 ft x 7.9 ft x 9.5 ft) | |||
| Ambient Temperature (Low and High Ambient Temperature Options Available) | -30 to 50°C (-22 to 122°F) | |||
| Electrolyte | Proton Exchange Membrane | |||
| Feed WaterConsumption | 0.9 l/Nm3 |
For reference only – specifications are subject to change. Please contact Nel Hydrogen for solutions to best fit your needs.
1Beginning of life and dependent on configuration and operating conditions.
